• For paint colour options, please replace -TB with required paint code.
• HT Applies for standard version. For any options, please contact technical sales on +44 (0)20 8254 2022 or email technical@designplan.co.uk.
• For Class II product with Surge Protection and In-rush Limiter, please add suffix -CB.
• For Class II product with Surge Protection, please add suffix -CC.
• For Class II product with In-rush Limiter, please add suffix -CD.
Technical Information
| Tuscan G2 Recessed Class II | Output (Lum/lm) | Load (W) | Efficacy (lm/W) | CCT (K) |
|---|---|---|---|---|
| L720mm | ||||
| TURCL-2-1700N-X-TB | 1679 | 14.4 | 117 | 4000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 4.8 | C | 150mm x 80mm | ||
| TURCL-2-2000N-X-TB | 2038 | 17.1 | 119 | 4000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 4.8 | C | 150mm x 80mm | ||
| TURCL-2-1600W-X-TB | 1579 | 14.4 | 110 | 3000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 4.8 | C | 150mm x 80mm | ||
| TURCL-2-1900W-X-TB | 1905 | 17 | 112 | 3000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 4.8 | C | 150mm x 80mm | ||
| L1293mm | ||||
| TURCL-4-3000N-X-TB | 3007 | 25.2 | 120 | 4000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 9.6 | C | 150mm x 80mm | ||
| TURCL-4-3900N-X-TB | 3933 | 32.3 | 122 | 4000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 9.6 | C | 150mm x 80mm | ||
| TURCL-4-3000W-X-TB | 2990 | 27.2 | 110 | 3000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 9.6 | C | 150mm x 80mm | ||
| TURCL-4-4000W-X-TB | 3962 | 36.2 | 110 | 3000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 9.6 | C | 150mm x 80mm | ||
| L1597mm | ||||
| TURCL-5-3500N-X-TB | 3484 | 29 | 120 | 4000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 12 | C | 150mm x 80mm | ||
| TURCL-5-4700N-X-TB | 4714 | 39.2 | 120 | 4000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 12 | C | 150mm x 80mm | ||
| TURCL-5-3400W-X-TB | 3374 | 29 | 116 | 3000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 12 | C | 150mm x 80mm | ||
| TURCL-5-4500W-X-TB | 4528 | 39 | 116 | 3000 |
| CRI (min) | Driver Lifetime (up to hours) | High Temp (°C) | LED Lifetime | |
| 80 | 100,000 | 45 | L₈₀B₁₀>102,000h | |
| Weight (kg) | LED Energy Rating | Dimensions | ||
| 12 | C | 150mm x 80mm | ||
